The narrow aisle forklift has been manufactured to function in narrow storage spaces by increasing the ratio between the space and the aisle width. Yale makes the double reach NDR and single reach NR units which are used for aisle widths between eight and ten feet. The Narrow Aisle trucks manufactured by Yale provide a Quadra-Flexx Operator Compartment that has various control handle and stance configurations and apply best-in-class ergonomics.
NDR & NR Productivity Enhancements
Quadra-Flexx Operator Compartment: There are numerous control handle configurations which meet a range of operations as well as a choice of fore and aft stance or side-stance options too.
AC Motor Technology: This technology offers strong deceleration and acceleration as well as fast lifting speeds. It has been made for quick plugging in order to facilitate more responsive directional changes that combine to increase the amount of loads moved during a shift.
Reach & Mast Assembly: The mast reach assembly consists of tapered roller and trunion mounting bearings. This increases the mast durability and rigidity; along with the reach assembly carriage that are reinforced for long life and the gusseted rear frame weldment.
Power Lowering: To greatly improve the overall throughput and production, Yale provides industry leading lowering speeds and uploading speeds.
Regenerative Lowering: Although regenerative lowering can lessen battery changes per shift it also functions to maintain a lower oil operating temperature.
Electronic Steering: The electronic steering eliminates the need for hydraulic pumps and therefore really reduces energy. The steering tiller is adjustable by the operator and the technician could adjust the steer effort in order to lessen operator fatigue. During the start-up process, drive tire centers automatically start.
Order Selectors: The narrow aisle trucks and the very narrow aisle trucks are also known as order pickers. These machines are designed for the manual handling of racked loads which are smaller than pallet size. These order selectors lift both the operator and the load to its required height. This height could be more than 30 feet. Similar with the majority of turret trucks they are generally rail or wire guided when used in very narrow aisle applications.
