Jib Crane Models
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes could transport loads between any areas within the boom's arc of rotation. Light duty models are utilized in warehouses and factories for loads weighing up to 5 tons. The website BestJibCranes.com features the major kinds of jib cranes as being either wall-mounted, mast mounted or free-standing.
Free Standing
Free-standing jib cranes are able to stand alone not needing support from the building structure. The horizontal boom in this case is attached to a pivoting vertical column which is anchored firmly to the building floor. This type of jib crane is able to rotate a full 360 degrees and requires a foundation made of either steel or concrete.
Mast-Type
The vertical column on the mast-type jib cranes are supported by pivot points at the bottom and the top. These pivots are attached to the building floor and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the advantage of not requiring the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes offer a horizontal boom which is attached to the wall of a building as opposed to the regular vertical column. These machinery provide up to 200 degrees of rotation and are ideal in areas where the full 360 degree rotation is not required.
There are two model varieties, depending on how the boom is supported. One of the kinds utilizes a tie rod which is connected from above the wall to the boom. The other type supports the boom from below by using a cantilever brace which is connected to the wall as well.
