Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in manufacturing construction machines. They manufacture equipment like aerial lifts, manlifts and boom lifts. These equipments are designed to facilitate access to difficult to reach areas, large equipment, roofs and buildings, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also called OSHA refers to a power-driven endless belt. This belt moves only in one direction and includes handholds or platforms or steps that are attached to the unit in order to transport employees from every floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, while the model's maximum width is 8.5 feet. The TB85 has dimensions that measure 9 inches wide and 9 feet, 1-inch high by 36 feet. This model provides a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The maximum height of Terex's TB100 man lift is 106 feet and the maximum height of the platform is 100 feet. The TB100 when stowed away, is around 9 feet high by 8.5 feet wide by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's overall maximum working height reaches 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 provides a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus ten degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
